50mm Intake Inducer
53mm Exhaust Exducer
Features
• Titanium Bullet Nose
• Fully Rebuildable/Upgradeable
• Anti-Surge Compressor Housing
• CTR 7/14 Billet Slim Hub Extended Tip Compressor Wheel
• Available in journal, oil Lubricated, oil-Less water-cooled and air-cooled oil-less
CTR Compressor Wheel Technology
The CTR-line of turbochargers features a compressor wheel that is 7-14 vaned and embodies the latest in compressor design technology. They feature a minimum diameter hub to maximize intake airflow and an extended tip design for increased efficiency at higher pressure ratios. The R-line design features, including maximum inducer diameters, produce higher boost pressures at high engine speeds and allow increases in engine HP output of up to 15%. The R-line of advanced design compressor wheels is now available on our complete line of CT turbochargers.
CTR High Flow Turbine Technology
The CTR Turbine wheels are 25% lower inertia leading to faster rotor acceleration. The slim hub and thin blade design make this wheel unique, while the design feature maximizes the flow capacity, increasing it by 30% more than the prior GT style Turbine wheel. The Comp Turbo CTR high flow turbine wheels have minimal leaving velocity due to a longer surface blade length; thus, leaving losses are minimized, which leads to higher turbine efficiency and greater flow range than available turbine wheels in the industry. CTR turbine wheels are designed where high exhaust flow capability is required and minimal leaving gas velocity increases turbine efficiency.
